Specification

The table below provides general and dimensions for Burro Docking Station

  • Dimensions included in both inches(in) and centimeters(cm).

  • Charging times provided for 10-100%

  • You may optionally plug the Grande or Verde, into a wall outlet if a nearby dock is unavailable. However, do not plug it in and dock it at the same time.

Dimensions

Spec

Values

Height

52.5 in (134cm)

Width (base mounting plate only)

15.6 in (40cm)

Width (with reflector plate)

19.3 in (49cm)

Depth

27.75 in (70.5cm)

AC Line Cord Length

48”

Technical Specifications

Spec

Values

Charging Power

1.5kW (1500W)

*Supported for Grande @ 220VAC

Compatible platforms

Burro Grande, Burro Verde

Input power

100-230 VAC; 50/60 Hz; 12A max.
*Dock configured to supply voltage

Charge time - Burro Grande

7 Hours @220VAC
10.5 Hours @120VAC

Charge time - Cortador (Grande w/ Extended Battery Pack, 20kWh total)

14 hours @ 220VAC
21 hours @ 110VAC (not recommended)

Charge time - Burro Verde

4 Hours @ 220VAC & 120VAC

Docking alignment

Lidar-based

  • Charge times for Burro Grande are for the the pair of batteries included in the base configuration

  • We also support standard outlets for regions outside the US.
